Main Functions:
01
When two series-excited motors are parallelly driven by one SCR cabinet to operate the same load, the chain wheel may cause one or both motors to lose the load and then overspeed. The drive of the mud pump falls into this category.
02
The role of the chain wheel anti-slip board is to detect whether the speed and load of the series-excited motors are normal. When the speed-to-load ratio exceeds a threshold, it is determined as a belt slip event.
03
When the chain wheel slips, the anti-slip board disconnects the assigned contactor, cuts off the power supply to the two motors, and simultaneously turns on the chain wheel slip indicator light on the panel.
System Components:
Anti-slip circuit detection board, Hall devices, and transformer.
Frequently Asked Questions
Q1: What is the primary purpose of the 0000-2003-00 PC05/08 board?
A: It is designed to detect speed and load imbalances in series-excited motors to prevent overspeeding during chain wheel slippage.
Q2: What happens when a slip is detected?
A: The board automatically disconnects the contactor, cuts power to the motors, and activates a visual slip indicator light.
Q3: Is this product compatible with mud pump drives?
A: Yes, it is specifically optimized for applications like mud pump drives where parallel motors operate under shared loads.
Q4: What materials are used in the construction of the board?
A: The board is manufactured using high-quality Aluminum and Organic Resin for superior insulation and durability.
Q5: What is the production capacity for this model?
A: We maintain a high production capacity of approximately 100,000 pieces per month to meet global demand.
Q6: Does the system include necessary sensors?
A: Yes, the complete system includes the detection board along with Hall devices and a transformer.
