📦 Basic Information
Source Flow
Active Inverter
Wave Form
Sine Wave Inverter
💡 Sine Wave Power Inverter With Charger (GPSW-II 1-6K)
🚀 Key Features
- Low Frequency Power Inverter with charger 1-6KW
- 2 in 1 Off Grid hybrid design: Inverter + Power Charger
- Selectable Grid power priority, Solar Power priority or Power Saver Modes
- Use as backup HOME UPS or Off grid solar inverter
- Low frequency toroidal transform, Pure sine wave with AVR
- LCD display with smart setup and simple operation
- Automatic Transfer Time less than 10ms
- Max 30A Adjustable Charge Current, selectable battery type
- Comprehensive protection for overload, short-circuit, and low battery
- Smart fan cooling and Alarm system
📊 Technical Specifications
| 1KW | 1.5KW | 2KW | 3KW | 4KW | 5KW | 6KW |
| Rated Power |
1000W | 1500W | 2000W | 3000W | 4000W | 5000W | 6000W |
| Efficiency |
>95% AC mode, >88% DC mode (Toroidal transformer) |
| Battery |
Voltage |
12/24/48VDC | 24/48VDC | 24/48VDC | 48/96VDC |
| Charge Current |
30A (Default), adjustable via LCD (C0-C6) |
| Output |
Wave Form |
Pure Sine Wave |
| Transfer Time |
< 10 ms (typical) |
| Attention |
The inverter does not build-in solar charger controller |
📷 Product Display
❓ Frequently Asked Questions
1. What is the transfer time for this inverter?
The automatic transfer time is less than 10ms, making it ideal for UPS applications to protect sensitive equipment.
2. Can I adjust the charging current?
Yes, the charge current is adjustable up to 30A (default) and can be configured through the LCD monitor (C0-C6).
3. Does it include a solar charge controller?
No, the GPSW-II model does not have a built-in solar charge controller. It is a power inverter with an AC charger.
4. What type of transformer does it use?
It uses a low-frequency toroidal transformer, which provides pure sine wave output and high efficiency.
5. Is it compatible with different battery types?
Yes, you can select different battery types (U0-U7) directly through the LCD setup menu.
6. What working modes are available?
It features Grid Power Priority (UPS mode), Battery/Solar Priority, and a Power Saver Mode for light loads.
