1. Hybrid Inverter is a high-quality inverter which can convert solar energy to AC energy and store energy into battery.
2. The inverter can be used to optimize self consumption, store in the battery for future use or feed-in to public grid. Work mode depends on PV energy and user's preference. It can provide power for emergency use during the grid loss by using the energy from battery and PV. Parallel function is available for off-grid models.
| Technical specification | R5KLNA | R6KLNA | R8KLNA | R10KLNA |
|---|---|---|---|---|
| Max. PV power (kW) | 7.5 | 9 | 12 | 13 |
| Max. DC voltage (V) | 500 | |||
| MPPT voltage range (V) | 125~500 | |||
| Rated output power (kVA) | 5 | 6 | 8 | 10 |
| AC output voltage (V) | 120/240 (split phase), 240 (single phase) | |||
| Battery voltage range (V) | 40~58 | |||
| CEC efficiency | 96.5% | |||
| Protection Degree | IP65 / NEMA 3R | |||
