The VRF air conditioners, also known as "one-to-many," is a type of system where one outdoor unit is connected to several indoor units. Each indoor unit can operate independently or be controlled together. The system has an outdoor unit connected by pipes to indoor units that have components like outdoor heat exchangers, compressors, and other parts.
Using the pipes, the outdoor unit can supply cooling liquid to many indoor units. It controls the compressor's cooling fluid circulation and the flow into various indoor heat exchangers to meet the indoor cooling and heating needs. The indoor temperature sensor controls the valve on the indoor unit's cooling pipe by adjusting the pressure and compressor speed.
| Description | Unit | Data (AirTS-C72) |
|---|---|---|
| Standard circulating air volume | m3/h | 12000 |
| Nominal cooling capacity | kW | 72 |
| Nominal heating capacity | kW | 68 |
| Nominal cooling input power | kW | 21.00 |
| Nominal heating input power | kW | 19.00 |
| Power supply | - | 3N~380V 50Hz |
| Refrigerant | - | R410A |
| Lateral air supply distance | m | >45 |
