| Model NO. | GYCH-MCA-01 |
| Address Line | 3 |
| Can | 3 |
| Transport Package | Carton Packaging |
| Specification | Customized |
| Trademark | OEM |
| Origin | China |
High voltage energy storage/industrial and commercial energy storage solutions use 3+1 level BMS architecture, integrated flexible networking mode, can support single cluster independent use or multiple cluster battery parallel use, can simultaneously online monitoring system total voltage, total current, insulation resistance, relay bonding, with cell safety state real-time monitoring, intelligent balancing, fault diagnosis, multi-level alarm and protection, combined with accurate SOX computing, and support mass data collection and storage, AI big data security early warning, battery performance monitoring and trend analysis, complex logic processing, local data storage and edge computing applications.
Meet the DC 1500V design, and support remote platform intelligent operation and maintenance, can be effectively extended battery life, improve system stability and security, and reduce equipment operation and maintenance costs.
| BMU Technical Specifications | |
|---|---|
| Operation Voltage | DC12V-36V |
| Operation Current | ≤ 35mA(12V)/≤ 20mA(24V) |
| CAN | 1 |
| Voltage acquisition strings | 16S~22S, 23S~44S, 45S~66S |
| Temperature sensors | 14~54 |
| Voltage acquisition accuracy | ±4mV |
| Balance | Supports Passive Balance |
| Size | 170*100*31.2mm / 360*120*31.2mm |
| Product parameters | BCU | BAU |
|---|---|---|
| Operation Voltage | DC12V-36V | DC12V-36V |
| CAN / RS485 | 3 / 2 | 3 / 5 |
| Ethernet | 1 | 3 |
| Insulation Detection | Support | Support |
| Size | 245*115*29.7mm | 245*106.5*29.7mm |
Established in 2011, we are a high-tech enterprise specializing in the research, development, production, and sales of lithium battery management systems (BMS). As a national-level "Little Giant" enterprise, we provide global customers with safe, intelligent, and efficient solutions.
With a strong R&D team and over 50 national patents, we have achieved digital and platform-based management of lithium battery safety. Our solutions are widely used in low-speed e-bikes, electric motorcycles, drones, and industrial energy storage scenarios.
